Datasheet Downloads
GT Biaxial Geogrid 2020S Datasheet.pdf

GT Biaxial Geogrid 20/20 S 4m x 50m

Product Code: 150WW4023-Pro
In Stock

GT Biaxial Geogrid 20/20 S 4m x 50m is designed to provide ground stabilisation and reinforcement. High strength, combined with low elongation provides effective reinforcement. The aperture design of the geogrid allows the aggregate to interlock and encourages load dispersal, particularly in applications such as unpaved roads.

Quantity
- +
Price
£285.00
£237.50 Ex VAT
Add to Basket Buy

GT Biaxial Geogrid 20/20 S 4m x 50m is designed to provide ground stabilisation and reinforcement. High strength, combined with low elongation provides effective reinforcement. The aperture design of the geogrid allows the aggregate to interlock and encourages load dispersal, particularly in applications such as unpaved roads.

The GT Biaxial Geogrid 20/20 S will provide excellent ground stabilisation and reinforcement for a wide variety of civil engineering and construction projects. Through the interlock mechanism, GT Biaxial Geogrids are specifically designed to control the movement of aggregate materials. Using a geogrid as part of a civil engineering or construction project results in a significant reduction to the quantity of required fill material, as GT Biaxial Geogrids can increase the bearing capacity of the underlying ground offering enhanced performance and cost benefits to the overall project.

GT Biaxial Geogrid 20/20 S Features

  • The high strength and with low elongation of Lotrak® provides effective ground reinforcement
  • The aperture design of Lotrak® geogrids enables aggregate materials to interlock and encourages load dispersal
  • Lotrak® geogrids are manufactured under ISO Quality Management and the Construction Products Regulation

GT Biaxial Geogrid 20/20 S Benefits

  • Excellent Soil & Aggregate Confinement
  • High Tensile Strength
  • High-performance Reinforcement
  • Cost Effective Design Component

GT Biaxial Geogrid 20/20 S Roll Size

  • 4m x 50m
TEST STANDARD GT Biaxial Geogrid 20/20 S
Tensile Strength (kN/m) EN 10319 MD
CD
20
20
Tensile Strength at 2% strain (%) EN 10319 MD
CD
7
8
Tensile Strength at 5% strain (%) EN 10319 MD
CD
15
17
Elongation at max. load (%) EN 10319 MD
CD
12
9
Grid Opening Size (mm) EN 10319 40 x 40
Effect of UV Light The polypropylene (PP used contains a UV inhibitor
Roll Size (m) Width

Length

4

50
